gru 4, 2024
SONY TC-755A po SPA
Sony TC-755A
Stereo Tapecorder (1975-77)
Specifications
Track system: 4-track, 2-channel, stereo/monaural system
Reel size: up to 10.5 inch reel
Equalization: NAB
Tape speeds: 3 3⁄4 7 1⁄2 ips
Wow and flutter: 0.07% (7 1⁄2 ips)
Frequency response: 30Hz to 28kHz (7 1⁄2 ips)
Signal to Noise Ratio: 58dB
Total harmonic distortion: 0.8%
Input: 60mV (line), 0.2mV (mic)
Output: 0.775V (line)
Dimensions: 435 x 451 x 221mm
Weight: 24kg
wrz 21, 2024
HMK-70 Sony Music Center
Specifications
Type: Music Centre
Formats: turntable, tape, tuner
Loudspeakers: 3-way
Power output: 20 watts per channel into 8Ω
Frequency response: 40Hz to 20kHz
Total harmonic distortion: 0.9%
Dimensions: 626 x 191 x 430mm
Weight: 19.4kg
Year: 1975
wrz 7, 2024
Sony TC-377
General
- Manufacturer: Sony
- Model: TC-377 (designation in Japan for the identically constructed Sony TC-6360 A)
- Type: Reel-to-reel tape recorder
- Years of manufacture: 1972 – 1976
- Made in: Japan
- Color: silver / black, housing wood
- Remote control:
- Power consumption: 48 W
- Dimensions (WxHxD): 418 x 392 x 210 mm
- Weight: 11.5 kg
- Original price approx.: 950 DM
Connections
- Number of inputs:
- Line-In: 60 mV / 100 kOhm
- Microphone: 0.2 mV
- Number of outputs:
- Line-out: 775 mV / 100 kOhm
- Headphone: 8 Ohm
Technical Data
- Max. coil diameter: 18 cm
- Drive: 1 motor
- Heads: 3
- Tracks: 4
- Tape speeds: 4.75 cm/s, 9.5 cm/s, 19 cm/s
- Slip:
- Speed variations:
- 4.75 cm/s: 0.17 %
- 9,5 cm/s: 0,12 %
- 19 cm/s: 0.09
- Overall frequency response with Sony SLH tape:
- 4.75 cm/s: 30 – 20’000 Hz
- 9.5 cm/s: 30 – 25’000 Hz
- 19 cm/s: 20 – 30’000 Hz
- Signal-to-noise ratio: 55 dB (SLH band)
- Distortion factor: 1.2 % THD
- Equalization: NAB
- Crosstalk attenuation:
- Cancellation attenuation:
- Premagnetization and cancellation frequency: 160 kHz
Special Features
- Housing horizontally / vertically interchangeable
